- EVO502 pumped waste
- Breaktank as standard
- 500 x 500mm rack
- Maximum useable height 265mm
- Dimensions W600 x D600 x H710mm
- Height excludes adjustable feet which will add 10 - 20mm
- Three standard cycle time options
- Extensive range of special cycles
- Cycle times can be tailored to site requirements
- Power 2.6/4.5/6.5kW 13/20/30 Amps
- Polychromatic LCD display and user interface giving uncomplicated machine status updates
- Improved wash action from quick release parallel wash & rinse arm design
- Stainless steel scrap tray filters supplied as standard
- Improved triple wash tank filtration
- Four button control fascia with special programmes button, operational self-diagnostics & alarms menu
- Drain pump & breaktank supplied as standard
- Three standard cycle options with an extensive range of special cycles
- Cycle times can be tailored to site requirements
- Reduced water consumption
- Comprehensive automatic self cleaning at end of service
- Selectable energy saving mode
- Selectable thermostop ensures optimum rinse temperatures
- Fully double skinned minimising both acoustic output and reduced heat loss
- Patented dual flow wash pump with soft start - reducing power consumption whilst retaining wash efficiency
- Full door seal & door ajar facility
- Moulded wash tank for easy cleaning
- Moulded rack guide
- Accurate detergent and rinse aid peristaltic dosing pumps as standard
- Priming and dosing of chemicals enabled from fascia controls
- Supplied with two open cup/glass racks & cutlery insert
Product Specification
- Evo - undercounter EVO502
- Width x Depth x Height mm 600 x 600 x 710mm
- Feet Height 10mm-20mm
- Basket size 500x500mm
- Maximum useable height 265mm
- Door Opening 290mm
- Cycle times 90/120/150 Seconds
- Water consumption per cycle 1.8 Litres
- Wash tank capacity 15 Litres
- Phase - Options Single/3-Phase
- Power – Single Phase Options 2.6kW(13Amp),4.5kW(20Amp),
- 6.5kW(30Amp)
- Power – Three Phase 6.5kW(16Amp)
- Detergent pump Peristaltic-Non Timed
- Rinse aid pump Peristaltic-Non Timed
- Drain pump Yes
- Breaktank Yes
- Water supply pressure 2 to 4 Bar
- Body Construction Double Skin
- Door/Hood Construction Double Skin
- Scrap Trays Yes
- Internal Rinse Booster Pump Yes
- Number Of Cycles 3
- Total Maximum Load(as supplied) 6.5kW(30Amp) – Single Phase
